Advice on wiring Brushess DC motor, FIT0441

Support DFRobot
1

I need some wisdom,

I have a brushless DC motor, 159RM Fit0441, as per link below.

I would like to conect to a 12 power supply and ESP32 Wroom dev board.

I have wired up to board and power as per WIKI

with power -ve to board.

(FG not connected as waiting on resistor) but this should not be need to get motor to turn ?

however the motor does not turn.

My understanding is that with 12v applied, and a 3.3 volt feed to PWM ( wire 1) it should ?

Any advice good.
Or if you can suggest another way to run motor from 12v power adaptor, (speed control good, but not complusory)

Thanks

James

2

Hi James

The example seems to be centred around Arduino UNO which is probably a 5V PWM signal. So 3.3V might not be enough.

And the controller might be expecting a PWM signal, not a steady DC. Don’t know for sure as I am not very familiar with brushless drive controller details. I must do some research on this as this technology seems to be the go these days.
Cheers Bob
